Patching Process In Oracle

Create a folder for patch

1	`[oracle@node1 ~]$` `mkdir-p /data/patch`

2 . By Winscp move the patch zip file to /data/patch this location. 3. Now check the current opatch version.

1
2
3 [oracle@node1 ~]$ $ORACLE_HOME/OPatch/opatch versionOPatch Version: 12.2.0.1.17O
Patch succeeded.

#if the opatch version is old , then you have to replace it with the latest version. here it is 12.2.0.1.17. so let’s upgrade it.

1
2
3
4 [oracle@node1 ~]$ cd $ORACLE_HOME [oracle@node1 dbhome_3]$ [oracle@node1 dbhome_3]$ [oracle@node1 dbhome_3]$ mv OPatch/ OPatch_old

Now unzip the zip file to ORACLE_HOME LOCATION.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34 [oracle@node1 ~]$ cd /data/patch [oracle@node1 patch]$ [oracle@node1 patch]$ [oracle@node1 patch]$ ll total 2680620 -rw-r--r--. 1 oracle oinstall 2622069290 Aug 2 16:49 p33509923_190000_Linux-x86-64.zip -rw-r--r--. 1 oracle oinstall 122883929 Oct 29 13:02 p6880880_122010_Linux-latest-opatch-x86-64.zip [oracle@node1 patch]$ [oracle@node1 patch]$ [oracle@node1 patch]$ unzip p6880880_122010_Linux-latest-opatch-x86-64.zip -d $ORACLE_HOME Archive: p6880880_122010_Linux-latest-opatch-x86-64.zip creating: /data/app/oracle/product/19C/dbhome_3/OPatch/ inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/README.txt inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/datapatch inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/emdpatch.pl inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/operr_readme.txt creating: /data/app/oracle/product/19C/dbhome_3/OPatch/scripts/ . . . . . . . inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/thirdparty/xercesImpl-2.12.0.jar creating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/thirdparty/features/ inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/thirdparty/features/xercesimpl.jar inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/thirdparty/features/xercesimpl_2.12.0.0.0.jar inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/com.oracle.glcm.patch.opatch-common-api-schema_13.9.5.0.jar inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/com.sun.xml.bind.jaxb-xjc.jar inflating: /data/app/oracle/product/19C/dbhome_3/OPatch/modules/com.oracle.glcm.patch.opatch-common-api-interfaces_13.9.5.0.jar

Now again check the opatch verion :

1
2
3
4 [oracle@node1 patch]$ $ORACLE_HOME/OPatch/opatch version OPatch Version: 12.2.0.1.29 OPatch succeeded. [oracle@node1 patch]$

#now its 12.2.0.1.29

Now unzip p33509923_190000_Linux-x86-64.zip to same location.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38 [oracle@node1 patch]$ ll total 2680620 -rw-r--r--. 1 oracle oinstall 2622069290 Aug 2 16:49 p33509923_190000_Linux-x86-64.zip -rw-r--r--. 1 oracle oinstall 122883929 Oct 29 13:02 p6880880_122010_Linux-latest-opatch-x86-64.zip [oracle@node1 patch]$ [oracle@node1 patch]$ [oracle@node1 patch]$ unzip p33509923_190000_Linux-x86-64.zip Archive: p33509923_190000_Linux-x86-64.zip creating: 33509923/ creating: 33509923/33575402/ inflating: 33509923/33575402/README.txt creating: 33509923/33575402/etc/ creating: 33509923/33575402/etc/config/ inflating: 33509923/33575402/etc/config/inventory.xml inflating: 33509923/33575402/etc/config/actions.xml creating: 33509923/33575402/files/ creating: 33509923/33575402/files/wlm/ creating: 33509923/33575402/files/wlm/mesg/ . . . . . . . . . inflating: 33509923/33529556/files/crs/sbs/logging.properties.sbs inflating: 33509923/33529556/files/crs/sbs/rootcrs.sbs inflating: 33509923/33529556/files/crs/sbs/ohasd.sles.sbs inflating: 33509923/33529556/files/crs/sbs/crsconfig_dirs.sbs creating: 33509923/33529556/etc/ creating: 33509923/33529556/etc/config/ inflating: 33509923/33529556/etc/config/inventory.xml inflating: 33509923/33529556/etc/config/actions.xml inflating: 33509923/33529556/README.txt inflating: PatchSearch.xml [oracle@node1 patch]$

now give all permissions to patch

1 2	`[oracle@node1 patch]$ cd ..` `[oracle@node1 data]$ chmod-R 777 patch/`

Now unzip p33509923_190000_Linux-x86-64.zip to same location.

8. Check Conflicts

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 [oracle@node1 data]$ $ORACLE_HOME/OPatch/opatch prereq CheckConflictAgainstOHWithDetail -phBaseDir /data/patch/33509923/33515361 Oracle Interim Patch Installer version 12.2.0.1.29 Copyright (c) 2022, Oracle Corporation. All rights reserved. PREREQ session Oracle Home : /data/app/oracle/product/19C/dbhome_3 Central Inventory : /data/app/oraInventory from : /data/app/oracle/product/19C/dbhome_3/oraInst.loc OPatch version : 12.2.0.1.29 OUI version : 12.2.0.7.0 Log file location : /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_14-29-57PM_1.log Invoking prereq "checkconflictagainstohwithdetail" Prereq "checkConflictAgainstOHWithDetail" passed. OPatch succeeded. [oracle@node1 data]$

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19 [oracle@node1 ~]$ $ORACLE_HOME/OPatch/opatch prereq CheckConflictAgainstOHWithDetail -phBaseDir /data/patch/33509923/33529556 Oracle Interim Patch Installer version 12.2.0.1.29 Copyright (c) 2022, Oracle Corporation. All rights reserved. PREREQ session Oracle Home : /data/app/oracle/product/19C/dbhome_3 Central Inventory : /data/app/oraInventory from : /data/app/oracle/product/19C/dbhome_3/oraInst.loc OPatch version : 12.2.0.1.29 OUI version : 12.2.0.7.0 Log file location : /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_14-32-11PM_1.log Invoking prereq "checkconflictagainstohwithdetail" Prereq "checkConflictAgainstOHWithDetail" passed. OPatch succeeded. [oracle@node1 ~]$

now create /tmp/patch_list_gihome.txt file and add

12	`/data/patch/33509923/33515361/data/patch/33509923/33529556`

12	`[oracle@node1 patch]$ cd ..[oracle@node1 data]$` `chmod-R 777 patch/`

these 2 lines in it .

1
2
3
4 [oracle@node1 data]$ cd [oracle@node1 ~]$ [oracle@node1 ~]$ vi /tmp/patch_list_gihome.txt [oracle@node1 ~]$

now check whether there is any systemspace issue

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 [oracle@node1 ~]$ $ORACLE_HOME/OPatch/opatch prereq CheckSystemSpace -phBaseFile /tmp/patch_list_gihome.txt Oracle Interim Patch Installer version 12.2.0.1.29 Copyright (c) 2022, Oracle Corporation. All rights reserved. PREREQ session Oracle Home : /data/app/oracle/product/19C/dbhome_3 Central Inventory : /data/app/oraInventory from : /data/app/oracle/product/19C/dbhome_3/oraInst.loc OPatch version : 12.2.0.1.29 OUI version : 12.2.0.7.0 Log file location : /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_14-35-56PM_1.log Invoking prereq "checksystemspace" Prereq "checkSystemSpace" passed. OPatch succeeded.

so there is no systemspace issue.

now connect to sqlplus utility and check for invalid object count

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36 [oracle@node1 ~]$ sqlplus / as sysdba SQL*Plus: Release 19.0.0.0.0 - Production on Sat Oct 29 14:38:50 2022 Version 19.3.0.0.0 Copyright (c) 1982, 2019, Oracle. All rights reserved. Connected to an idle instance. SQL> startup ORACLE instance started. Total System Global Area 1744828000 bytes Fixed Size 9135712 bytes Variable Size 419430400 bytes Database Buffers 1308622848 bytes Redo Buffers 7639040 bytes Database mounted. Database opened. SQL> SQL> select count (*) invalid_objects from user_objects where status = 'INVALID' ; INVALID_OBJECTS 0 SQL> SQL> shu immediate; Database closed. Database dismounted. ORACLE instance shut down. SQL> SQL> SQL> exit Disconnected from Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production Version 19.3.0.0.0

Now go to patch folder and execute apply command.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61 [oracle@node1 ~]$ cd /data/patch [oracle@node1 patch]$ ll total 2682068 drwxrwxrwx. 8 oracle oinstall 4096 Jan 13 2022 33509923 -rwxrwxrwx. 1 oracle oinstall 2622069290 Aug 2 16:49 p33509923_190000_Linux-x86-64.zip -rwxrwxrwx. 1 oracle oinstall 122883929 Oct 29 13:02 p6880880_122010_Linux-latest-opatch-x86-64.zip -rwxrwxrwx. 1 oracle oinstall 1478442 Jan 20 2022 PatchSearch.xml [oracle@node1 patch]$ cd 33509923/ [oracle@node1 33509923]$ [oracle@node1 33509923]$ [oracle@node1 33509923]$ ll total 136 drwxrwxrwx. 4 oracle oinstall 48 Jan 13 2022 33239955 drwxrwxrwx. 5 oracle oinstall 81 Jan 13 2022 33515361 drwxrwxrwx. 5 oracle oinstall 62 Jan 13 2022 33529556 drwxrwxrwx. 5 oracle oinstall 62 Jan 13 2022 33534448 drwxrwxrwx. 4 oracle oinstall 48 Jan 13 2022 33575402 drwxrwxrwx. 2 oracle oinstall 4096 Jan 13 2022 automation -rwxrwxrwx. 1 oracle oinstall 5824 Jan 13 2022 bundle.xml -rwxrwxrwx. 1 oracle oinstall 123797 Jan 20 2022 README.html -rwxrwxrwx. 1 oracle oinstall 0 Jan 13 2022 README.txt [oracle@node1 33509923]$ [oracle@node1 33509923]$ [oracle@node1 33509923]$ cd 33515361/ [oracle@node1 33515361]$ $ORACLE_HOME/OPatch/opatch apply Oracle Interim Patch Installer version 12.2.0.1.29 Copyright (c) 2022, Oracle Corporation. All rights reserved. Oracle Home : /data/app/oracle/product/19C/dbhome_3 Central Inventory : /data/app/oraInventory from : /data/app/oracle/product/19C/dbhome_3/oraInst.loc OPatch version : 12.2.0.1.29 OUI version : 12.2.0.7.0 Log file location : /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_14-47-01PM_1.log Verifying environment and performing prerequisite checks… OPatch continues with these patches: 33515361 Do you want to proceed? [y|n] y . . . .. . . Patching component oracle.rdbms.rsf.ic, 19.0.0.0.0… Patching component oracle.precomp.common, 19.0.0.0.0… Patching component oracle.precomp.lang, 19.0.0.0.0… Patching component oracle.jdk, 1.8.0.201.0… Patch 33515361 successfully applied. Sub-set patch [29517242] has become inactive due to the application of a super-set patch [33515361]. Please refer to Doc ID 2161861.1 for any possible further required actions. Log file location: /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_14-47-01PM_1.log OPatch succeeded.

To check how many patches applied on database

1	`[oracle@node1 33515361]$` `$ORACLE_HOME/OPatch/opatch lsinventory \| grep` `"applied on"`

Go to another patch folder and execute apply command.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17 [oracle@node1 33509923]$ cd 33529556 [oracle@node1 33529556]$ $ORACLE_HOME/OPatch/opatch apply Oracle Interim Patch Installer version 12.2.0.1.29 Copyright (c) 2022, Oracle Corporation. All rights reserved. Oracle Home : /data/app/oracle/product/19C/dbhome_3 Central Inventory : /data/app/oraInventory from : /data/app/oracle/product/19C/dbhome_3/oraInst.loc OPatch version : 12.2.0.1.29 OUI version : 12.2.0.7.0 Log file location : /data/app/oracle/product/19C/dbhome_3/cfgtoollogs/opatch/opatch2022-10-29_16-03-28PM_1.log Verifying environment and performing prerequisite checks… . . . . .

Connect to sqlplus utility and check invalid object count. Also make all pluggable database open.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28 [oracle@node1 ~]$ sqlplus / as sysdba SQL*Plus: Release 19.0.0.0.0 - Production on Sat Oct 29 16:06:06 2022 Version 19.14.0.0.0 Copyright (c) 1982, 2021, Oracle. All rights reserved. Connected to an idle instance. SQL> startup ORACLE instance started. Total System Global Area 1744827992 bytes Fixed Size 9135704 bytes Variable Size 419430400 bytes Database Buffers 1308622848 bytes Redo Buffers 7639040 bytes Database mounted. Database opened. SQL> SQL> SQL> alter pluggable database all open; Pluggable database altered. SQL> select count(*) invalid_objects from user_objects where status= 'INVALID'; INVALID_OBJECTS --------------- 0

now execute ./datapatch -verbose command.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22 [oracle@node1 33529556]$ cd $ORACLE_HOME/OPatch [oracle@node1 OPatch]$ ./datapatch -verbose SQL Patching tool version 19.14.0.0.0 Production on Sat Oct 29 16:57:35 2022 Copyright (c) 2012, 2021, Oracle. All rights reserved. Log file for this invocation: /data/app/oracle/cfgtoollogs/sqlpatch/sqlpatch_17770_2022_10_29_16_57_35/sqlpatch_invocation.log Connecting to database...OK Gathering database info...done. . . . . . . . . . SQL Patching tool complete on Sat Oct 29 17:13:26 2022 [oracle@node1 ~]$ cd $ORACLE_HOME/network/admin [oracle@node1 admin]$

Now go to patch folder and execute apply command.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61 [oracle@node1 admin]$ sqlplus / as sysdba SQL*Plus: Release 19.0.0.0.0 - Production on Sat Oct 29 17:16:28 2022 Version 19.14.0.0.0 Copyright (c) 1982, 2021, Oracle. All rights reserved. Connected to an idle instance. SQL> startup ORACLE instance started. Total System Global Area 1744827992 bytes Fixed Size 9135704 bytes Variable Size 687865856 bytes Database Buffers 1040187392 bytes Redo Buffers 7639040 bytes Database mounted. Database opened. SQL> alter pluggable database all open; Pluggable database altered. SQL> select count(*) invalid_objects from user_objects where status= 'INVALID'; INVALID_OBJECTS 0 SQL> SQL> SQL> desc dba_registry_sqlpatch; Name Null? Type INSTALL_ID NOT NULL NUMBER PATCH_ID NOT NULL NUMBER PATCH_UID NOT NULL NUMBER PATCH_TYPE NOT NULL VARCHAR2(10) ACTION NOT NULL VARCHAR2(15) STATUS NOT NULL VARCHAR2(25) ACTION_TIME NOT NULL TIMESTAMP(6) DESCRIPTION VARCHAR2(100) LOGFILE NOT NULL VARCHAR2(500) RU_LOGFILE VARCHAR2(500) FLAGS VARCHAR2(10) PATCH_DESCRIPTOR XMLTYPE PATCH_DIRECTORY BLOB SOURCE_VERSION VARCHAR2(15) SOURCE_BUILD_DESCRIPTION VARCHAR2(80) SOURCE_BUILD_TIMESTAMP TIMESTAMP(6) TARGET_VERSION VARCHAR2(15) TARGET_BUILD_DESCRIPTION VARCHAR2(80) TARGET_BUILD_TIMESTAMP TIMESTAMP(6) SQL> SQL> SQL> select PATCH_ID, STATUS from dba_registry_sqlpatch; PATCH_ID STATUS 29517242 SUCCESS 33515361 SUCCESS Patch is applied successfully.
